Cnc od grinder and thread grinder

Discussion in 'Other Builds' started by Mark and Oreo, Jun 12, 2019.

  1. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Mark and Oreo published a new build:

    Read more about this build...

  2. Alex Chambers

    Alex Chambers Master
    Moderator Builder

    Joined:
    Nov 1, 2018
    Messages:
    843
    Likes Received:
    437
    Welcome to the forum. Looking forward to what seems like an interesting build.
    Alex.

  3. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Here is the 2nd half of the build team. I use him with any thing I don't understand smartoreo_zps523d4375.jpg

  4. Alex Chambers

    Alex Chambers Master
    Moderator Builder

    Joined:
    Nov 1, 2018
    Messages:
    843
    Likes Received:
    437
    Shouldn't be any problem with the technical stuff then.
    Alex :ROFL::ROFL::ROFL:

  5. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Parts for the z axis have come in. Time to mount them on the base plate. I think I'm going to buy a pre built 100 mm axis for the xaxis


    Attached Files:

  6. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    The steeper motors are nema 34 840 oz. Still not sure about the motion control. I really need cutter comp and a way to measure and adjust comp for dressing the wheels.

  7. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Any suggestions that don't require a serial port to control this would be great. (I already had a cnc lathe and mill on linux. Would rather have something a little simpler and don't want to try and find another 10 year old computer. )

    #7 Mark and Oreo, Jun 22, 2019
    Last edited: Jun 22, 2019
  8. sharmstr

    sharmstr Master
    Moderator Builder

    Joined:
    Mar 23, 2018
    Messages:
    834
    Likes Received:
    467
    Clearly the brains of the team. :)

  9. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Yes he is.

  10. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    NEED ADVICE looking for a usb motion controller for 3 axis 3 limit switches. 2 home switches. 3 position like tool height sensors. A spindle control and 2 relay switches. Any suggestions appreciated. I would like to keep it under 100. But have some flexibility. Also I will be running either mach 3 or mach 4.

  11. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Most of the electronics getting laid out. Waiting for a few limit switches and a few other things. Mechanical parts or still on the way


    Attached Files:

  12. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Well ran into a little problem with what I wanted to use to drive my grinding wheels. I planned to remove the motor from a harbor freight angle grinder and mount it with timing gears. When I took it apart the bearing and outer housing are all the handle. Plastic and crappy. I bought a 300 watt spindle and then did the math. 12v for 3000 rpm. 300 watts equals 25 Amps. So new power supply for the spindle is on the way.

  13. Mark and Oreo

    Mark and Oreo Well-Known
    Builder

    Joined:
    Jun 12, 2019
    Messages:
    10
    Likes Received:
    2
    Well got a little update. Almost finished with the mechanical parts, time to get on the electronics almost.


    Attached Files:

    Peter Van Der Walt likes this.
